sTOP
SPOTTING.
START
TREATING.
The SWIFT System runs in tandem with your cleanout BHA to deliver full wellbore cleanout and selective, pressure-driven treatment — in a single workover trip.
♦ FIELD RESULT • KARNES COUNTY • EAGLE FORD • MAY 2026
4X
PRODUCTION
12 → 50 bbl/d • 30 days
1
One workover trip. Same rig time as a conventional acid spot.
CLEANOUT + STIM
Single trip • Industry first
23
ACID STAGES
Individually placed
0
ADDED RIG DAYS
vs. a spot job
♦ FIELD RESULT • KARNES COUNTY, TX
AN INDUSTRY FIRST,
ON A RIG ALREADY ON LOCATION
“THE RIG WAS ALREADY ON LOCATION. THE CREW WAS ALREADY COMMITTED. USING SWIFT, WE DELIVERED A FULL WELLBORE CLEANOUT PLUS 23 INDIVIDUALLY-PLACED ACID STAGES, EACH DRIVEN INTO THE FORMATION UNDER CONTROLLED PRESSURE DIFFERENTIAL. NOT SPOTTED. NOT POOLED. PLACED.”
KARNES COUNTY • EAGLE FORD • WORKOVER • MAY 2026
♦ HOW IT WORKS
PRESSURE DRIVES FLUID INTO THE FORMATION.
SWIFT INJECTS; IT DOESN’T JUST SPOT.
SWIFT builds differential pressure between two metal-to-metal restrictors and injects through a single flow-activated port — placing treatment into the formation, not just the wellbore. With no rubber elements and a slim 4.1” OD, it passes restrictions and deformed casing that stop conventional packer systems.
OPERATOR
SCOPE AS-RIGGED
SCOPE ADDED
STAGES PLACED
METHOD
TOTAL TIME
ADDED RIG DAYS
30-DAY PRODUCTION
Eagle Ford workover, Karnes County, TX
Wellbore Cleanout
Confirmed selective stimulation - same trip
23, individually, under pressure differential
Not spotted. Not pooled. Pressure-driven.
Two Days - same rig time as a conventional acid spot
Zero
Up 4x — from 12 to 50 bbl/d (operator reported)
01 / Port
TREATMENT PORT
Flow-activated injection port meters fluid between the restrictors across a wide range of rates while the BHA stays set.
02 / Restrictors
FLOW RESTRICTORS
Fully retractable, metal- to-metal restrictors limit bypass — forcing treatment into the formation between them
03 / Materials
NO RUBBER
Removing elastomers enables a more rigorous cleanout, more stages per trip, faster operations, and broader chemical compatibility.
04 / Recovery
CONTINGENCIES
Fully fishable — a ball-drop disconnect and multiple circulation points keep operations recoverable in any scenario.
BUILT FOR THE WELLBORES THAT STOP OTHER TOOLS
PARAMETER
Casing Size
Casing Weight
Max OD
Max Pressure
Max Temperature
Max Rate
IMPERIAL
5.5 in
17 - 23 lb/ft
4.100 in *
0.75 in **
350 °F
30 BPM
METRIC
139.7 mm
25.3 - 34.2 kg/m
104.1 mm
19.1 mm
176 °C
4.77 m3/min
* OD of total body; centralizer OD varies with casing weight. ID through the bottom restrictor at the ball seat.
♦ Wellbore cleanout
♦ Selective zonal treatment
♦ Restimulation
♦ Chemical / acid injection
♦ Damage removal
APPLICATIONS
♦ One-trip cleanout + treatment
♦ Mill circulate & treat — one BHA
♦ Injects treatment into the formation
♦ Runs past casing restrictions
♦ Enables future interventions
BENEFITS
♦ SPECIFICATIONS • APPLICATIONS
♦ FIELD-PROVEN HERITAGE
BUILT ON EXCITE — THOUSANDS
Of STAGES, EVERY MAJOR U.S.
BASIN, INTERNATIONALLY.
SWIFT inherits a multi-year field record from Comitt’s EXCITE platform. The mechanics, the materials, the operational envelope — proven across every major U.S. basin and abroad before SWIFT was ever named.
♦ GET IN TOUCH
HAVE A WORKOVER IN THE SCHEDULE?lET’S TALK.
REQUEST A SWIFT BRIEFING
-30 minutes. Engineer on the call.
